380V 220V 50va~10kVA Single Phase Custom Bk Series Voltage Converter Dry Type Isolation Control Transformer

Shop our Bk Series Voltage Converter Transformer for reliable single phase power conversion. Our factory-direct products are designed for 380V and 220V with 50va to 10kVA capacity.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
BK
Usage
Single-phase Transformer, Rectifier Transformer, Combined Transformer, Power Transformer, Distribution Transformer
Frequency Characteristics
Power Frequency
Shape of Core
OD
Brand
Sntooma
Transport Package
Standard Export Packing
Specification
500-2
Trademark
OEM
Origin
Zhejiang, China
Production Capacity
60000PCS/Month

Product Description

380V 220V 50va~10kVA Single Phase Custom Bk Series Voltage Converter Dry Type Isolation Control Transformer
BK series machine tool control transformers apply to be used as control power, working light of general electric appliance and mechanical equipment of various trades, and power of signal lamp with AC50-60Hz, input voltage doesn't exceed 1000V, output voltage doesn't exceed 600V. Our transformers provide optimal protection through high permissible ambient temperatures up to 40 or 55 , a high short-time rating in the case of control transformers, fuseless construction and due to its safety standard "Safety inside" to EN 615
Model
Dimensions(open type)(mm)
Mounting hole distance(mm)
Mounting holes(mm)
B  max
D  max
E   max
A
C
K*J
BK25-50VA
78
68
87
52±0.5
52±0.5
4.8*9
BK-100VA
84
82
94
64±0.5
64±0.5
4.8*9
BK-150VA
96
98
106
81±0.5
81±0.5
5.8*11
BK-200VA
96
105
106
88±0.5
88±0.5
5.8*11
BK-250VA
96
108
106
91±0.5
91±0.5
5.8*11
BK-300VA
120
117
114
97±0.5
97±0.5
7*13
BK-400VA
132
124
124
104±0.5
104±0.5
7*13
BK-500VA
132
124
124
104±0.5
104±0.5
7*13
BK-700VA
132
134
124
114±0.5
114±0.5
7*13
BK-1000VA
150
153
142
128±0.5
128±0.5
8*13
BK-1500VA
192
147
177
122±0.5
122±0.5
8*13
BK-2000VA
192
167
177
152±0.5
152±0.5
8*13
BK-3000VA
215
220
240
160±0.5
160±0.5
8*13
BK-5000VA
260
220
280
160±0.5
160±0.5
8*13
BK-10KVA
300
220
290
170±0.5
170±0.5
8*13

380V 220V 50va~10kVA Single Phase Custom Bk Series Voltage Converter Dry Type Isolation Control Transformer 380V 220V 50va~10kVA Single Phase Custom Bk Series Voltage Converter Dry Type Isolation Control Transformer 380V 220V 50va~10kVA Single Phase Custom Bk Series Voltage Converter Dry Type Isolation Control Transformer 380V 220V 50va~10kVA Single Phase Custom Bk Series Voltage Converter Dry Type Isolation Control Transformer 380V 220V 50va~10kVA Single Phase Custom Bk Series Voltage Converter Dry Type Isolation Control Transformer

OEM Services

1. Logo
Please offer us your own high resolution logo in JPG format,there should be two colors at most in the logo and there should be no gradient effect in the logo.

2. Label
Please offer us your own model numbers.

3. Manual
Please offer us the finished manual file that can be printed directly.

Lead Time

1.Sample orders will be delivered from our factory within 3-5 working days.
2.General orders will be delivered from our factory within 7-15 working days.
3.Large orders will be delivered from our factory within 45 working days at most.

Shipment

1.By EMS,DHL,FedEx,TNT,UPS or other Express.
2.By our forwarding agent(by Air or by Sea).
3.By your own forwarding agent.
4.By domestic forwarding agents to any city in China.

Our Company

YUEQING SHUNTONG IMP&EXP CO.,LTD is one of subsidiary of SHUNTONG ELECTRIC CO.,LTD , focus on import and export business.

SHUNTONG ELECTRIC CO.,LTD is a large new technical professional manufactor on security products such as warning lights, siren ,audible visual alarm, voltage stabilize & regulator and so on. It is one of the member of China Supply Institute , the member of professional institute of "Household AC automatic voltage regulator"

After so many years of developing and management , now Shuntong has become one of the best enterprises with quickly growing up in security field. The products are widely exported to over 50 countries . We hold a good share in market because of the good quality and services . we won a perfect reputation from users.

Shuntong staff insist on studying and trying to promote market   based on technology  and continue to innovate the  service for society .We emphasize technical management for fast evelopment.
380V 220V 50va~10kVA Single Phase Custom Bk Series Voltage Converter Dry Type Isolation Control Transformer

FAQ

Q 1.What's the payment term?
A. We accept TT,LC,Western Union,Paypal.

Q 2.What is the delivery time?
A. It depends on order quantity,usually it will take about 3-5 days for sample production.

Q 3.What's the package used for?
A. For the small capacity,will use carton,but for big capacity,we should use honeycomb carton and pallet or wooden case for protection.

Q 4.Would you accept to use our logo?
A.It's no problem,we accept OEM service.

Q 5.What's your production capacity for one month?
A. Our month capacity can reach near 500-3000pcs for the most of our model.

Q 6.Where is your market?
A. Our products are popular in Australia,South America,Philippines,Italy, America, Pakistan and so on.Some of them are our regular customers and some of them are developing. We hope you can join us and make mutural benifit from our cooperation.

Q 7. What kind of certificates you have?
A. Our company has ISO9001,CE, RoHS,SGS etc.

Contact us

Please feel free to give your inquiry in the form below We will reply you in 24 hours
